SPECIFICATIONS



Mass ( without guide bar and chain) : 7.50 (kg)

Dimensions ( without guide bar and chain) : 410x235x265 (mm)

Fuel : Mixture (Gasoline 25: Two-cycle oil 1)

Fuel tank capacity : 550 (ml)

Chain oil : Motor oil SAE#10W-30

Oil tank capacity : 260 (ml)

Engine displacement : 52 (cm3)

Maximum engine power : 2.2 kw/8500rpm

Maximum engine speed with cutting attachment : 10000rpm

Maximum Engine speed at idling : 3200rpm

Maximum cutting length : 50CM

Sound pressure level : 85dB(A)

Sound power level : 112dB(A)

The level of square acceleration

Front handle a : 9.36 m / s2

Back handle a : 9.22 m / s2

Sprocket : 7Tx0.325

Saw chain type : K2

Saw chain pitxh : 0.325 (in)

Saw chain gauge : 0.058 (in)

Guide bar type : Sprocket nose

Guide bar size : 22 (in)

Oil feeding system : Automatic pump with adjuster
